PowerBass XL-805DMX 800W RMS Monoblock Powersports Amplifier
Regular price
$375.99
Couldn't load pickup availability
The PowerBass XL-805DMX delivers compact monoblock power for marine, UTV and other outdoor audio systems. Its sealed construction, die-cast end caps and conformal-coated circuit board help protect the electronics in demanding environments. Class D circuitry and an aluminum heatsink support efficient operation where space is limited.
Features
- Sealed water-resistant housing; manufacturer specifies an IPX67 rating.
- Conformal-coated four-layer circuit board.
- RCA and 3.5mm auxiliary audio inputs.
- Adjustable low-pass crossover, gain and bass boost.
- Remote gain control included.
- Protection against overload, short circuits, overheating and DC output.
Specifications
| Manufacturer part number | XL-805DMX |
|---|---|
| 4-ohm output at 14.4V | 350W RMS |
| 2-ohm output at 14.4V | 500W RMS |
| 1-ohm output at 14.4V | 800W RMS |
| Frequency response | 10–300 Hz |
| Low-pass crossover | 40–300 Hz |
| Bass boost | 0–18dB at 45 Hz |
| Dimensions | 10 x 4.6 x 1.8 inches |
Installation and included items
Includes the amplifier and remote gain control. Subwoofer and installation wiring are sold separately. Match the amplifier to the subwoofer's final impedance, secure all connections and install fused power wiring according to the manual.
